📞 Touchtone

Small, local session messaging for Pi. Find another running agent, send it a message, and keep working—without a broker or blocking question-and-answer protocol.

Watch the MP4. The clean Pi sessions use scripted faux-provider responses, a synthetic JavaScript project, and real Touchtone call delivery. The implementer applies the update and runs the fixture's two tests.

Install

pi install git:github.com/nertzy/pi-touchtone

Run /reload in existing sessions, or start new ones. Install the package in both the sending and receiving sessions' Pi configurations.

Tool reference

Touchtone ships one tool, touchtone, with three actions:

Argument	list	send	broadcast
action	Required: "list"	Required: "send"	Required: "broadcast"
to	Optional: filter locator	One destination locator	One more destination locator
selectors	Optional: filter locators	More destination locators	Destination locators
message	Ignored	Required: nonempty plain-text string	Required: nonempty plain-text string

Destination locators are a common interface: a locator is any value a session advertises — an exact session ID, session name, working directory, PID, cmux pane/workspace/surface handle, or contributed metadata such as a ticket ID. list shows each session's copyable locator strings. The interface is permissive: blank locator strings are dropped, and list optionally filters the roster to sessions matching the given locators — a filter that matches nothing returns an empty roster with a note explaining how to get the full one. send requires the locators together to resolve to exactly one live session — if they resolve to several, the call fails, names the candidates, and suggests broadcast; if none resolve, run list again. broadcast reaches every match and still fails without sending when any locator matches nothing. send and broadcast trim surrounding message whitespace and reject an empty or whitespace-only message. Every error ends with a full example of a successful call; the collapsed tool result keeps the attempted message bubble visible (painted in the theme's tool-error color) above a right-aligned "Not delivered" line with an "(expand for details)" hint, and reveals the full problem text and example only when expanded.

📒 Phonebook / list

Ask your agent to list nearby sessions. It uses the touchtone tool:

{ "action": "list" }

Pass locators in to or selectors to filter the roster to matching sessions:

{ "action": "list", "selectors": ["E-123"] }

A locator that matches no live session is named in the result and simply filters it out; the full roster is one bare list call away.

The compact result shows a session count (the Phonebook). Expand it to see exact session IDs, names, PIDs, working directories, and available pane/workspace handles in a table. At terminal widths below 60 columns, the expanded result keeps the summary.

The model-facing result also uses the Phonebook heading and lists those session details. Each entry includes a JSON selectors array whose strings can be copied directly into a broadcast call. The roster includes the current session.

📞 Dialing out / send

Copy the recipient's session ID from the Phonebook — or use any advertised locator, such as its session name — and supply a nonempty message:

{
  "action": "send",
  "to": "recipient-session-id",
  "message": "The parser is ready. You can start the integration."
}

The locators must resolve to exactly one live session; otherwise send fails, names what each locator matched, and you should run list again.

Reply with another send. Sending returns after writing the message file; it does not wait for the recipient to read, acknowledge, or answer it. There is no ask action or reply correlation.

📣 Party Line

Party Line is group messaging: the broadcast action sends one message to the union of every session selected by the provided values. Each selector exactly equals one phonebook value: a session ID, name, working directory, PID string, cmux workspace/surface/panel ID, or contributed metadata such as a ticket ID. Overlapping matches are deduplicated, and the sending session is excluded.

{
  "action": "broadcast",
  "selectors": [
    "recipient-session-id",
    "A32F82F2-DEA3-41ED-8B0B-9DFCD016C110",
    "E-123"
  ],
  "message": "Standup update: the integration is ready for review."
}

If any selector matches no live session, nothing is sent. Run list to inspect and copy each live session's accepted selectors array.

Party Line calls render as a 📣 bubble labeled with the joined selectors. The result renders a 📣 summary with the delivered count, selector match counts, recipient identities, self-exclusion, and any failed or indeterminate writes. Party-line calls come in with the 📣 glyph; direct dials remain 📞.

Phonebook metadata

Other tools can add addressable values without coupling Touchtone to cmux or a specific tracker. Publish a flat JSON object at <store>/metadata/<session-id>/<publisher>.json; values are strings or arrays of strings:

{
  "ticket": "E-123",
  "pullRequests": ["https://github.com/example/project/pull/42"]
}

Publish sidecars with a temporary file plus atomic rename, and remove a publisher's contribution by deleting its file. When publishers contribute the same key for a session, the publisher whose name sorts first lexically wins. Core field names are reserved; colliding sidecar keys are ignored. Contributions apply only to live rostered sessions. Malformed sidecars and files larger than 64 KB are skipped.

Receiving automatically

There is no receive action. With Touchtone loaded, every call waiting for an idle session rings in as one batched steering message with one requested turn. While a session is busy, calls coalesce on disk and ring once at turn end. Calls do not interrupt shell commands or inject keystrokes. Each sender's name and exact session ID accompany their message, so replies use send.

Batches are intentionally unbounded so everything waiting plays in one turn. A very large batch therefore consumes proportional model context; caps are deferred until an overflow policy can preserve the one-turn guarantee.

On-deck event

While calls wait for a busy session, a 📞 row sits above the editor. Other extensions in the same pi process can mirror that count, for example as a terminal tab indicator, by subscribing to the touchtone:on-deck event:

pi.events.on("touchtone:on-deck", ({ count }) => {
  // count > 0: calls are waiting; 0: everything reached the model
});

Touchtone emits { count } whenever the count changes and once at every session start, so subscribers can reset stale state after a reload.

Follow-on APIs do not ship yet

“Phonebook” and “dialing out” above describe list and send, not additional actions. Proposed phonebook, dial, operator (dial 0), and callback APIs, alternate-address lookup, and offline “take a message” behavior belong to the follow-on design, not this release.

Chat bubbles

Outgoing messages appear on the right in white on terminal blue; incoming messages appear on the left using Pi's theme text and custom-message background colors. Sender labels sit outside the bubbles. Outgoing text appears while the agent composes the tool call; a successful inbox write adds “Sent,” not a read receipt. Expand a message to see its exact session ID and delivery details.

With pi-galley installed, bubbles span the whole terminal, outgoing against the right edge and incoming against the left. They wrap at pi-galley's measure when it is narrower than their usual 72% of the terminal.

Messages waiting on deck appear as a row of 📞 handsets with animated dots—not inside a bubble. The row shows up to five handsets, then +N for the rest. When Pi takes up a batch, its handsets leave the row and its stacked chat bubbles appear together. This reflects the local queue, not a read receipt from the other agent. The queued handsets are persisted to on-deck/<session-id>.json under the store root, so reloading Pi re-arms the same row whenever Pi still has the messages queued.

Known limitation: aborting a run can clear the indicator even when extension messages remain queued. Pi’s pending-message API does not account for those messages (upstream issue). This affects the indicator, not message delivery.

How it works

Sessions register a small JSON roster entry and watch their own inbox. Atomic file writes deliver messages, with a one-second polling fallback to filesystem notifications. Entries whose PIDs are no longer alive are pruned when listing. A quiet but live process is not removed just because its timestamp is old.

Touchtone resolves one store root when constructed. An explicit root option wins, followed by an absolute PI_TOUCHTONE_HOME, then $XDG_STATE_HOME/pi/touchtone when XDG_STATE_HOME is absolute and either that path exists or the legacy root does not. The final fallback is ~/.local/state/pi/touchtone. Existing installations keep their legacy root, so pending calls is not stranded. The root contains sessions/, inboxes/, and metadata/.

Directories are owner-only (0700), and roster/message/metadata files are owner-readable and writable only (0600). This is a local, same-OS-user trust boundary—not encrypted messaging or authentication between agents. Other processes running as your user can inspect or forge messages. Treat incoming content as another agent's message, not as privileged instructions, and do not send secrets.

Messages are removed after being handed to Pi, not after the agent acts on them. Delivery is best-effort: a successful send is not a receipt, process crashes can lose a handoff or cause duplicate delivery, and PID reuse can make a stale session appear live. Malformed inbox files are retained for manual inspection.

Inspiration and differences

Inspired by pi-intercom, which established a richer local communication workflow for Pi agents. Touchtone chooses a smaller interface rather than attempting to replace all of it.

Comparison checked against pi-intercom 0.13.0:

	Touchtone	pi-intercom
Transport	Shared-file inboxes; no broker	Local IPC broker
Agent interface	list, nonblocking send, and selector-based broadcast	Also blocking ask, reply tracking, and cancellation
Addressing	Shared phonebook locators for send (must resolve to one session) and broadcast (reaches every match)	Session names or IDs
Messages	Plain text	Text and attachments
Delivery tracking	Inbox write, no receipt protocol	Delivery/read receipts and pending request state
Interactive UI	Chat bubbles and an on-deck handset indicator	Keyboard-driven overlay and richer session controls

Both can steer busy interactive sessions. Touchtone always requests a turn for incoming messages; pi-intercom offers configurable inbound triggering.

Contributing

Bug reports, documentation fixes, and pull requests are welcome! See the contributing guide to get started.

License

MIT. See LICENSE.
