pi-better-render

Streaming-first rich rendering for pi's TUI. Markdown, code blocks, tables and LaTeX formulas are rendered as the answer streams in, with formulas shown as real images. It is built for Ghostty and kitty, and also shows formula images in other terminals with Kitty graphics, such as WezTerm.

• Display only. It replaces the component that displays a message and never edits the message. The session file and the next LLM request keep the original Markdown/LaTeX. As a safety net, a context hook also strips any terminal image artifacts before every request.
• Formulas while streaming. Each formula becomes an image as soon as it is complete. There is no waiting for the message to end.
• In process, no big runtime. No browser, Pandoc or daemon is involved. A formula takes about 1 ms from TeX to PNG.
• Text-like images. Formula images use Kitty Unicode placeholders. Each image is sent once; after that it behaves as ordinary text cells, so it wraps, scrolls and diffs like text. Inline formulas sit inside the line. Formulas stay in the scrollback after pi exits.

Compared with other pi extensions

	pi-better-render	pi-math	pi-markdown-preview	pi-rich-renderer
Where it shows	In the chat, automatically	In the chat, automatically	Separate viewer (/preview), browser or PDF	In the chat, automatically
Updates while streaming	✅ Markdown and formulas, on every delta	✅ Formulas	❌ On demand; watch mode refreshes after each completed reply	❌ Only when the message ends
Restyles Markdown (headings, callouts, tables, code)	✅	❌ pi's built-in	✅ As a Pandoc HTML page	❌ pi's built-in
Formulas inside the text line	✅	✅	✅ Inside a page screenshot	❌ Each formula becomes a block image
Math engine	MathJax 4, with optional TeX fallback	MathJax 3	Pandoc MathML + MathJax in Chromium	latex + dvipng per formula
Needs beyond npm install	Nothing (TeX is optional)	Nothing	Pandoc and Chromium; LaTeX for PDF	A TeX installation
Stored message and LLM context	Untouched (display only)	Untouched (display only)	Untouched (read only)	Message content replaced at message_end; original restored for the LLM
Terminals with images	Ghostty, kitty; WezTerm, Warp via direct placements	Ghostty, kitty; display formulas also in WezTerm, Warp, iTerm2	Ghostty, kitty, iTerm2, WezTerm	Those supported by pi's image component
Without images	Unicode approximation	Original LaTeX	–	Original LaTeX
Beyond chat rendering	Mermaid diagrams as Unicode art	Custom macros and environments	Browser and PDF export, Mermaid, file preview, export tool	Disk cache of PNGs

Each existing extension covers one part of the problem:

• pi-math typesets formulas in the chat but leaves the rest of the Markdown to pi.
• pi-markdown-preview renders a complete, polished page, but in a separate viewer after the reply has finished.
• pi-rich-renderer needs a TeX installation and swaps in images only once the message ends.

pi-better-render fills the gap between them. It renders the whole answer, Markdown structure and math alike, in the chat while it streams, in process, with nothing extra to install.

The others are still the better choice in some cases. For PDF or browser output, or for Mermaid diagram types beyond flowchart, sequence, state, class and ER, use pi-markdown-preview. For formula images in iTerm2, use pi-math. (Comparison as of September 2026.)

What it renders

Element	Rendering
Headings	H1 with a ━ rule, H2 with a ─ rule, H3 as ▍ title, H4–H6 by color. No # markers
Emphasis	bold, italic, strikethrough, inline code, clickable links (OSC 8) with the URL shown
Lists	• ◦ ▪ by depth, original numbering, ☑/☐ tasks, hanging indent
Quotes	▎ bar. GitHub callouts > [!NOTE], [!TIP], [!IMPORTANT], [!WARNING], [!CAUTION]
Code	Background block, language label, pi's syntax highlighting, ↪ wraps, optional line numbers, no fences
Tables	Rounded borders, bold header, :-: alignment, correct CJK widths. Columns shrink, then fall back to cards
Mermaid	```mermaid flowchart, sequence, state, class and ER diagrams drawn with box characters (correct CJK widths). The renderer is downloaded on the first diagram (see below). Other types, invalid source or diagrams wider than the terminal stay as code
Rules	Full-width ─
Math	See below

Copying code

In Pi's fullscreen mode, completed code blocks have a Copy button in the upper-right corner. Click it to copy the source without fences, line numbers or visual line wrapping. The button briefly shows Copied on success. If the clipboard is unavailable, it stays Copy and an error notification explains the failure. Keyboard focus stays in the editor, and dragging over the code body still selects text normally.

Buttons are hidden in regular terminal mode, on unfinished fences, or when the block is too narrow. Mermaid blocks rendered as diagrams do not have a code-copy button; use /better-render mermaid to show their source instead.

Math

• Delimiters: inline $…$ and \(…\); display $$…$$, \[…\] and \begin{align}… (plus the other AMS environments).
• TeX packages: AMS, mathtools, physics (\dv, \pdv, \qty, \abs, \norm), mhchem (\ce), braket, cancel, cases, empheq, bbm/dsfont/bboldx (\mathbbm, \mathds), color, boldsymbol, upgreek, gensymb, units, extpfeil, centernot, bussproofs, amscd.
• Extra macros: \bm, \llbracket/\rrbracket, and a single \tag{…}.
• CJK text: text inside formulas, such as \text{中文} or \text{한국어}, is rendered with a system CJK font. Without one (common on Linux servers and containers), Noto Sans SC (10 MB, Han and kana) or KR (6 MB, Hangul) is downloaded once into ~/.pi/agent/better-render/fonts, checked against a pinned SHA-256. The formula shows as text until the font arrives, then as an image.
• Fallback: if MathJax rejects a formula and a local latex+dvipng or tectonic is installed, that engine typesets it in the background. Where images are not possible, formulas use pi's Unicode approximation.

Performance

Measured on an Apple M-series laptop.

MathJax 4 + resvg startup (background, after session start)	~105 ms
Formula, TeX → SVG	~0.3 ms
Formula, TeX → SVG → PNG on the cell grid	~1 ms
Formula with CJK text	~10 ms
Streaming delta at the end of a 61k-character answer	~0.6 ms per frame
Streaming delta, 3.8k-character answer	~0.04 ms per frame

Streaming cost stays nearly flat as a message grows, for these reasons:

• Incremental lexing. Only the last two blocks are lexed again; earlier tokens are reused.
• Block cache. Rendered blocks are cached by token identity, so finished blocks are never rendered again.
• Formula cache. Formula rasters are cached by TeX, color and cell size, and each image is sent to the terminal only once.
• Images travel with their frame. An image is sent together with the frame that first shows it. pi does a full clear on resize, and its fullscreen mode deletes all image placements when its own images change; after either, images are sent or placed again, so formulas survive resizes and redraws. Images are never deleted when pi exits, so formulas left in the scrollback keep showing.

Run npm run bench to reproduce the streaming numbers.

How it works

assistant delta ─▶ incremental lexer (marked) ─▶ block renderer + cache ─▶ ANSI lines ─▶ pi-tui
                                                   │
                                                   └─ formula ─▶ MathJax 4 (TeX → SVG)
                                                                  ─▶ resvg (SVG → PNG, cell-exact)
                                                                  ─▶ Kitty graphics, virtual placement
                                                                  ─▶ U+10EEEE placeholder cells in the line

Part	Technology
Host	pi extension API. It patches the assistant message component and registers a context hook
Markdown	marked lexer (via pi-tui), with its own incremental re-lexing and block renderers
Code highlighting	pi's theme highlighter
Math typesetting	MathJax 4 (@mathjax/src, New Computer Modern font), in process and synchronous
Rasterizing	@resvg/resvg-js (Rust, native). Canvases are sized to whole terminal cells, so images are never stretched
Terminal images	Kitty graphics protocol: Unicode placeholders (Ghostty, kitty), or direct placements of one image slice per row (WezTerm, Warp and other terminals with Kitty graphics)
Fallback	Optional latex+dvipng or tectonic in a sandboxed child process. No shell escape, paranoid file access, 15 s timeout

Install

pi install npm:pi-better-render                       # from npm
pi install git:github.com/JeffeyChou/pi-better-render
pi -e npm:pi-better-render                            # try it for one run without installing

From a local checkout:

npm install
pi install ./path/to/pi-better-render                 # or: pi -e ./src/index.ts

Images need a terminal with the Kitty graphics protocol. Ghostty and kitty use Unicode placeholders. Other terminals that pi detects as Kitty-capable (WezTerm, Warp) get direct placements: the frame going to the terminal places one slice of the image per row, in the cells where its placeholders would be. Images are unavailable inside tmux/screen and in terminals without Kitty graphics. There, formulas use pi's Unicode approximation and everything else still renders.

Commands

/better-render takes one of these arguments:

• status shows the renderer state, the math engine, cache hit rates and formula timings.
• on / off turns rich rendering on, or switches back to pi's built-in Markdown.
• math:streaming, math:final or math:off controls when formulas become images.
• lines toggles line numbers in code blocks.
• mermaid toggles drawing ```mermaid blocks as diagrams (off shows their source). The diagram renderer (beautiful-mermaid, about 11 MB with its layout engine) is not installed with the package. The first ```mermaid block installs the pinned version with npm into ~/.pi/agent/better-render/deps in the background; the block shows as code until then and turns into a diagram when it arrives.
• clear-cache drops cached renders and frees the images sent to the terminal (formulas already in the scrollback go blank). Ending a session never frees them.

Environment variables:

• PI_BETTER_RENDER_DEBUG=1 logs context-sanitizer checks to ~/.pi/agent/better-render-debug.log.
• PI_BETTER_RENDER_TEX=off|latex|tectonic picks the TeX fallback.
• PI_BETTER_RENDER_MERMAID_INSTALL=0 never downloads the Mermaid renderer (diagrams stay as code unless beautiful-mermaid is already installed).
• PI_BETTER_RENDER_DEPS_DIR changes where it is downloaded (default ~/.pi/agent/better-render/deps).
• PI_BETTER_RENDER_FONT_DOWNLOAD=0 never downloads a CJK font; PI_BETTER_RENDER_FONTS_DIR changes where it goes.
• PI_BETTER_RENDER_IMAGES=placeholder|direct|off overrides terminal detection. PI_BETTER_RENDER_PLACEHOLDERS=0|1 still works (1 forces placeholders, 0 turns images off).

Development

npm test                                                  # unit tests (rebuilds vendor/ first)
npm run build                                             # rebuild vendor/ (the trimmed MathJax)
npm run typecheck
npm run bench                                             # streaming cost per delta
npm run preview -- test/fixtures/perceptron.md            # render a file in this terminal
npm run preview -- test/fixtures/perceptron.md --stream   # also time the streaming path
npm run preview -- test/fixtures/perceptron.md --live     # animate the stream on screen

MathJax is a development dependency. npm run build bundles the parts the renderer uses into vendor/ (about 12 MB, most of it on-demand font data), so an install is about 15 MB instead of 118 MB. vendor/ is committed because pi installs git packages with npm install --omit=dev and no build step. MathJax is pinned to exact versions and the build is deterministic, so vendor/ only changes when those pins change (the build refuses ranges or a drifted node_modules); vendor/README.md lists what it contains. Without vendor/, the code loads MathJax from node_modules directly.

Publishing:

npm pack --dry-run   # the tarball holds src/, vendor/, README.md, LICENSE and package.json
npm publish          # runs typecheck and tests first (prepublishOnly)

The pi-package keyword lists the package in the pi package gallery.

Credits

MathJax (Apache-2.0) is bundled in vendor/; see vendor/LICENSE.

The Kitty diacritic table and the formula-scaling approach are adapted from Fadouse/pi-math (MIT).

License

MIT
