pi-mm: Intelligent Persistent Memory for Pi Coding Agent

Multi-resolution persistent memory for the Pi Coding Agent powered by native C engines (libcorm, libsepal, liblemma).

pi-mm gives your Pi Coding Agent long-term memory that survives context compaction and cross-session restarts. It automatically injects relevant prior technical decisions into context before each turn and captures new learnings when tasks conclude—with zero manual configuration.

---

1. Quickstart: Zero-Configuration Bring-Up

Install the extension:

pi install npm:@tty-pt/pi-mm

pi-mm works out of the box:

1. Automatic Daemon Startup: Checks if axil-auren is running on port 4242. If offline, it brings up the local server automatically.
2. Automatic Model Provisioning: Discovers models in ~/.models/ and auto-downloads the required fast embedding model (bge-base, 117 MB) with sha256 verification. Heavy and unused inference/chat models are never downloaded. Shows non-blocking visual progress (⬇ bge-base (42%)) and usage status (⚡ bge-base) in the status bar (mm-judge).
3. Proactive Dependency Checks: On session_start, pi-mm automatically checks core C engines (libcorm, libsepal, liblemma, libjoint, axil, axil-auren) and displays actionable remediation toasts if anything is missing.

Verify Memory Health

Inside Pi, run:

/mm doctor

Outputs live endpoint connectivity, latency, loaded models, storage footprint, and core C engine versions.

---

2. Agent Tools Reference

By default, pi-mm exposes 3 focused tools to keep the agent's context clean and avoid tool ambiguity:

Tool	Parameters	Description
memory_recall	query, overview, zoomRef, project, level, includeEvidence	Multi-resolution retrieval: search semantically, generate all-time timeline overviews (overview: true), or zoom vertically into a specific investigation (zoomRef: 42).
memory_record	problem, approaches, diffs, findings, outcome, verification	Explicitly records an episode, bug fix, or project invariant with verified test commands.
memory_review	ref, action, lifecycle, reason, evidenceRef	Inspects memory evidence hierarchy (action: "inspect") or transitions factual lifecycle status (action: "update_lifecycle").

Advanced fine-grained tools (memory_store, memory_scan, memory_think, memory_forget, etc.) can be enabled via "advancedTools": true.

---

3. Diagnostic & Timeline Commands

Command	Description
/mm doctor	Displays live status for decision judge, vector endpoints, storage file sizes, and core C engines.
/mm overview	Synthesizes an all-time structured timeline across active principles (L3), invariants (L2), and milestones (L1).
/mm timeline	Chronological grouping of memory capture epochs and historical activity.

---

4. Configuration Reference

Configure settings in .pi/settings.json (or user ~/.pi/agent/settings.json):

Option	Default	Description
captureEmbedUrl	"http://127.0.0.1:4242"	Endpoint URL for in-memory semantic classification (POST /v1/classify). Independent of embedUrl, which feeds the memory index
captureEmbedModel	"bge-base"	Classification embedding model (a multilingual model improves non-English recall)
captureMode	"all", or "judge" when captureEmbedUrl is set in your settings	What automatic conversational capture stores: "all" (every user turn), "keyword" (only turns starting with a capture keyword), "judge" (turns the embedding classifier says are worth remembering), "off"
captureEmbed	"auto"	Classify turns by embeddings in captureMode: "judge". Env: PI_MM_CAPTURE_EMBED
captureMinSimilarity	0.6	Cosine floor for any embedding verdict (0..1)
captureMinMargin	0.075	How far a "remember" verdict must beat "skip" (0..1); raise it to store less, lower it to store more
captureExemplars	{}	Your own example sentences, { "remember": [...], "skip": [...] }, any language, merged with the shipped ones
judgeFallback	"skip"	Deterministic fallback when the classifier server is offline ("skip" or "capture")
autoStartAuren	true	Automatically launch axil-auren in the background if offline
autoDownloadModels	"manual"	Model download policy ("manual" prompts for heavy models, "auto" downloads without prompting)
semanticSearch	true	Enable dense vector embeddings and semantic recall via libsepal
embedUrl	"http://127.0.0.1:4242/v1/embeddings"	Embedding generation endpoint
embedModel	"bge-base"	Embedding model identifier ("bge-base" for 768-d, "bge-small" for 384-d)
advancedTools	false	Expose the 9 advanced low-level memory inspection tools
recallEmbed	"auto"	Classify user prompts by embeddings (POST /v1/classify) to detect recall intent ("auto" or "off"). Env: PI_MM_RECALL_EMBED
recallMinSimilarity	0.6	Cosine floor for recall intent embedding classification (0..1)
recallMinMargin	0.08	How far a "recall_past" verdict must beat "standalone" (0..1)
recallExemplars	{}	Your own example sentences, { "recall_past": [...], "standalone": [...] }, merged with shipped ones
recallFallback	"regex"	Fallback when classifier endpoint is offline: "regex" (deterministic heuristics) or "skip"
recallAction	"hint"	Action on recall inquiry or architectural wonder: "hint" (default, zero DB queries, emits epistemic hint advising agent to use memory_recall via inference) or "query" (legacy auto-injection). Env: PI_MM_RECALL_ACTION
wonderingEmbed	"auto"	Classify assistant turns and thoughts by embeddings (POST /v1/classify) to detect cognitive wonderings and architectural curiosity ("auto" or "off"). Env: PI_MM_WONDERING_EMBED
wonderingMinSimilarity	0.6	Cosine floor for assistant wondering embedding classification (0..1)
wonderingMinMargin	0.08	How far a "wondering" verdict must beat "routine_action" (0..1)
directiveEmbed	"auto"	Classify user prompts by embeddings (POST /v1/classify) to detect standing directives/rules ("auto" or "off"). Env: PI_MM_DIRECTIVE_EMBED
directiveMinSimilarity	0.6	Cosine floor for standing directive classification (0..1)
directiveMinMargin	0.08	How far a "standing_directive" verdict must beat "transient_task" (0..1)
directiveExemplars	{}	Custom examples { "standing_directive": [...], "transient_task": [...] } merged with shipped ones
directiveFallback	"regex"	Fallback when endpoint is offline: "regex" or "skip"
overviewEmbed	"auto"	Classify direct memory inquiries by embeddings (POST /v1/classify) to detect open-ended overviews ("auto" or "off"). Env: PI_MM_OVERVIEW_EMBED
overviewMinSimilarity	0.6	Cosine floor for overview routing classification (0..1)
overviewMinMargin	0.08	How far an "overview_query" verdict must beat "specific_query" (0..1)
overviewExemplars	{}	Custom examples { "overview_query": [...], "specific_query": [...] } merged with shipped ones
overviewFallback	"regex"	Fallback when endpoint is offline: "regex" or "skip"
judgeProtocol	(deprecated)	Deprecated in favor of POST /v1/classify
judgeModel	(deprecated)	Deprecated in favor of POST /v1/classify
judgeUrl	(deprecated)	Deprecated; mapped to captureEmbedUrl

Automatic Capture: What Decides What

captureMode decides whether anything is judged at all. Recall questions ("do you remember ...") are never captured, in any mode. In keyword and judge modes a turn that starts with a capture keyword (@remember, remember:, note: by default) is always stored, without consulting anything; in all mode every other turn is stored too.

captureMode	What stores a turn	If that is unavailable
all	Every user turn. No classifier and no embeddings are consulted.	n/a
keyword	Only turns that start with a capture keyword	n/a
judge	In-Memory Embedding Classification via POST /v1/classify	Deterministic judgeFallback (skip stores nothing, capture stores the turn)
off	Nothing automatic	n/a

captureMode resolves to all unless you set it or put a judgeUrl in your settings (which implies judge). If you never set either, the embedding tier below never runs.

Why embeddings for judge mode: on English/Portuguese turns the default judge model (olmoe) answered "remember" to 40 of the 44 turns that were not worth remembering (greetings, thanks, recall probes, task requests; counted over two corpora of 22 such turns each), i.e. it stored almost everything. Measured on the held-out corpus of 44 new turns:

	Embeddings (bge-base)	Judge (olmoe)
Accuracy	26/44 (59%)	24/44 (55%)
False "remember" (a wrong store)	0	20
Real memories recognised	4/22 (7/22 on the development corpus)	22/22
Latency (p50)	~15 ms	~1.9 s

Read that honestly: embeddings are high-precision and low-recall. They store few turns and almost never the wrong one, so most casual statements are not captured automatically; say @remember ... for the ones that matter, add captureExemplars in your own phrasing, or lower captureMinMargin to store more. The first held-out run failed the adoption rule (3 false "remember"); the exemplar set was then extended by form and a hypothesis recorded before a fresh corpus confirmed it. bge-base is English-only, so Portuguese statements mostly fall back to "skip" until you add examples or use a multilingual model.

Measure your own phrasing (opt-in, never part of npm test; prints accuracy, false "remember", latency and every miss for both strategies): PI_MM_EVAL_JUDGE=1 deno test --allow-all --sloppy-imports tests/eval/ (set PI_MM_EVAL_URL for a non-default server).

Proactive Recall Intent: What Drives Context Injection

In addition to write-path capture judging, pi-mm intelligently classifies the read path before each agent turn (before_agent_start). When a user asks about past architectural choices, previous debugging sessions, decisions, rules, or lore, pi-mm uses POST /v1/classify against a curated bilingual exemplar corpus (recall_past vs standalone):

1. Hint-Only Architecture (recallAction: "hint", default): When recall intent or architectural wondering is confirmed by embeddings, auto_recall executes zero automated database scans (runScanWithTimeout and primeSubsystemInvariants are completely bypassed). Instead, it injects a quiet epistemic hint into event.systemPromptOptions.sections["memory_context"] advising the agent to formulate queries via LLM inference and retrieve records using memory_recall. It sets display: false on the returned custom message, completely eliminating noisy, unprompted UI cards in the user's chat interface. For legacy auto-injected background recall, set "recallAction": "query".
2. Lifting Unprompted Suppression: In general conversational turns without memory keywords, context injection is conservative. When recall_past intent is confirmed by embeddings, unprompted context filtering is lifted, allowing vector and hybrid retrieval to surface relevant memories even without exact subsystem matches.
3. Actionable Agent Steering: When recall intent is positive, pi-mm augments the agent's system prompt sections (memory_context) with explicit guidance directing the model to inspect memory_recall (and zoomRef if candidate records are retrieved) before guessing or invoking irrelevant bash or grep tools.
4. Resilient Offline Fallback: If axil-auren is offline or unconfigured, pi-mm seamlessly falls back to deterministic heuristics (recallFallback: "regex").

Daemon Circuit Breaker & Resilient Timeout

All embedding classification and vector calls to axil-auren are wrapped with a resilient in-memory circuit breaker (src/judge/circuit.ts):

• Fast Timeout: Imposes a tight default timeout of 250 ms (DEFAULT_CLASSIFY_TIMEOUT_MS = 250) on /v1/classify, well above normal local inference (~18 ms p50) but fast enough to prevent perceptible turn lag.
• Fail-Fast Cooldown: On connection refusal (ECONNREFUSED), socket hang, network error, or 5xx server status, the daemon base URL is placed on a 30-second cooldown (CIRCUIT_BACKOFF_MS = 30_000).
• Zero Overhead When Offline: While the circuit is open, subsequent calls bypass network I/O completely and return null immediately (measured at ~1 µs, 0 ms overhead), ensuring that Pi never freezes or stalls when axil-auren is stopped.

Assistant Cognitive Wondering Detection & Self-Hinting

When the agent expresses cognitive uncertainty, architectural curiosity, or wonders how a subsystem works mid-task:

• Examples: "I wonder how the caching layer works in this project", "Not sure how FTS handles accent folding here", "Where are session files stored in this architecture?"
• pi-mm intercepts the assistant's turn in message_end and evaluates the reasoning via vector embeddings (POST /v1/classify on axil-auren, bge-base).
• When classified as wondering (similarity $\ge 0.60$, margin $\ge 0.08$), the system steers the agent via pi.sendMessage (deliverAs: "steer"):

  💡 [Memory Hint]: You are exploring how this subsystem, convention, or architecture works. Check memory_recall to consult past technical decisions and lore.

• Zero automated database scans are run in the background, ensuring no speculative database queries and zero UI pollution. The agent uses its own inference to query memory_recall.
• Measured Accuracy: 100.0% accuracy (24/24), 100.0% recall, and 0.0% false positives (p50: 17.9 ms) across bilingual wondering and routine action benchmarks (npm run eval:wondering or scripts/eval-wondering.ts).

Empirical Benchmark: Regex Heuristics vs. Embeddings

Measured on a held-out, bilingual (English + Portuguese) corpus of 44 realistic turns (22 recall_past queries, 22 standalone engineering tasks), completely disjoint from training exemplars (npm run eval:recall against axil-auren with bge-base):

Metric	Previous Heuristic Gate (isMemoryRecallPrompt)	axil-auren Embeddings (POST /v1/classify)	Impact / Delta
Overall Accuracy	56.8% (25/44)	81.8% (36/44)	+25.0% accuracy
Recall Catch Rate (recall_past)	13.6% (3/22)	63.6% (14/22)	4.7× improvement (+11 caught)
Task Specificity (standalone)	100.0% (22/22)	100.0% (22/22)	Zero regressions / zero false recall
False Positives	0	0	Zero unwanted memory spam
Latency (p50 / p95)	< 1 ms	17 ms / 34 ms	Fast, imperceptible C SIMD execution

Run the recall evaluation suite against your live axil-auren instance:

npm --prefix .pi/extensions/pi-mm run eval:recall

npm test is hermetic: it preloads tests/no-live-network.ts, which refuses any request to the real auren port (4242) or to a non-loopback host, and runs with PI_MM_AUTO_START_AUREN=0 so no local server is started. Run with PI_MM_ALLOW_LIVE=1 to lift the guard.

---

5. Prerequisites & Core C Engines

pi-mm uses compiled C engines for sub-microsecond in-memory retrieval:

Engine	Description	Build & Guide
libcorm	In-memory key-value store, unified recall kernel, and cormd daemon.	libcorm
libsepal	Pure-C Approximate Nearest Neighbor (ANN) dense vector store.	libsepal
libjoint	Interval-tree temporal presence engine for historical co-occurrence.	libjoint
liblemma	Diacritic-preserving full-text search tokenizer (pão ≠ pao).	liblemma
axil-auren	Local LLM inference, embeddings, and fast decision judging.	axil-auren

Prebuilt packages are available via tty.pt packages for APT, Homebrew, and pacman.

---

6. Development & Verification

npm --prefix .pi/extensions/pi-mm test             # Run hermetic test suite (450+ tests)
npm --prefix .pi/extensions/pi-mm run lint         # Lint all TypeScript source and scripts
npm --prefix .pi/extensions/pi-mm run eval:recall  # Benchmark recall intent classification against live auren
npm --prefix .pi/extensions/pi-mm run eval:surfaces # Benchmark directive, overview, and kind classification
npm --prefix .pi/extensions/pi-mm run test:playbook # Non-destructive bootstrap verification playbook
npm --prefix .pi/extensions/pi-mm run demo          # Interactive live bootstrap demonstration
npm --prefix .pi/extensions/pi-mm run zip           # Package distribution bundle

License

BSD 2-Clause License. Copyright (c) 2025, tty-pt. See LICENSE.
