Prototype · pi-proto

A framework-neutral design workspace with Pi as its agent. Its primary deliverable is a stable design guide: rationale, hierarchy, composition, typography/color roles, density, states and patterns to preserve or avoid. New pages extend that reasoning; an existing poor interface is a baseline, not a visual mandate. Tokens, guides and screens are separate deliverables. A component catalogue is optional, never a prerequisite.

proto_context retrieves bounded local project evidence, the current guide and pi-memory's supported project decisions in one call. It detects frontend packages and declared/resolvable libraries, links reusable sources and caches unchanged inputs. It does not scaffold, build, execute source code or call a model. Native Pi design requests receive this snapshot automatically. MCP callers retrieve their own memory; the daemon never opens a parallel memory database.

Install

pi install npm:@prjct.app/pi-proto

How it works

The daemon usually listens on port 51700; projects have separate URLs. Browser tabs and Pi sessions reconnect to it. There is no persistent idle/live TUI badge. PI_PROTO_VIEWER overrides the viewer folder; the legacy ~/.prjct/proto-viewer/dist is a fallback when the bundled viewer has not been built.

What goes in the workspace

Design guide: guide/<nn>-<slug>.md, in Markdown.

• Pages are ordered by their number.
• The title comes from front matter or the first # heading.
• A page may embed HTML with the same Tailwind classes the prototypes use, so colors, type and components show for real.

Tokens and shared patterns: guide/tokens.yaml.

Use proto_tokens to read/merge values from inspected references; existing values are preserved. New workspaces have no invented brand palette, font or prototype. The sample below is an example, not a default identity.

colors:
  brand: "#125e55"
  paper: "#ffffff"
radius:
  control: "8px"
components:
  btn-primary:
    as: button
    text: Continuar
    description: Acción principal
    class: "bg-brand text-paper rounded-control px-5 py-3 focus-visible:outline-2 focus-visible:outline-brand disabled:opacity-50"

Use class: btn-primary on prototype nodes. These patterns compile into Tailwind v4 utilities. Updating a definition refreshes all its uses through CSS without rewriting HTML. A component may also be a plain class string. Supported example tags are div, span, p, h1, h2, button, a, input, and textarea.

Prototypes: prototypes/<id>.yaml, with stable ids on pages and nodes. Change them through proto_edit operations, which create an undoable version. Nodes are spatial primitives (box, stack, row, grid, text, image, button, input, etc.). Click actions are on: {click: {go: page-id}}, {toggle: node-id}, or {back: true}. Only one page shows at a time. flow groups pages; group groups prototype variants for comparison. Neither grouping creates navigation by itself.

Design guide: guide/00-design.md, explicitly written with proto_design, a core of at most 500 words including references. Cover scope, source roles (target/current/constraint), visual rationale, composition, density, type/color roles, states/responsive rules, requested navigation, preserved/rejected patterns and pending decisions. It is not coupled to components, a framework or class names. Link detailed evidence and optional values rather than duplicating them.

Generated documentation: Tokens (10-tokens), optional existing patterns (20-components, only when explicitly defined), Sitemap (90-sitemap) and Entrega (95-handoff). Entrega is a compact index, not another design document. Full findings live in 96-checks.json, read on demand. Original guides/notes are preserved. Automatic checks do not certify fidelity or full accessibility.

The loop

1. You ask in Pi: "prototype the checkout, three variants".
2. The agent uses the requested artifact: proto_tokens, proto_design or prototype tools. proto_init prepares a workspace only; artifact: prototype explicitly creates its first page, and open_browser: true opts into opening the browser.
3. The agent receives fixed designer guidance once and a replaceable project-context snapshot, including bounded pi-memory evidence. The extension does not modify the system prompt per turn. Relevant guide/token changes refresh the snapshot; old copies do not accumulate.
4. You write in the composer docked at the bottom of the storybook, like Pi's editor.
   • Exact commands to open a named page or undo run locally, without a model or Pi. Edits go straight to Pi with the selected element's versioned YAML. Undo creates a recoverable version and is deferred while the agent is working.
   • Each browser tab supplies its own page context. Selecting an element includes its current YAML/version directly; opt-in inference can also suggest a target.
   • Text and images arrive as your user message. Attach, paste or drag images; images over 1800 px are scaled down.
   • It also switches the session's model and thinking level, in sync with Pi.
   • Sending is acknowledged immediately. The dock shows the real agent activity and streams its visible text, not its private reasoning. When the turn ends, the final answer appears in the conversation. The agent can also answer there with proto_reply.
5. Choose the deliverable in the composer or describe it in the message. Stop after that artifact. Native Pi tasks have default ceilings of 180 seconds, 12 model responses, 24 tool executions and 16,000 generated tokens. Reaching a ceiling aborts the run with a partial-result notice; saved work is not reverted. The viewer separates fresh input/output from cached input. These are safety ceilings, not speed or design-quality guarantees. They do not apply to unrelated Pi tasks or external MCP agents.
6. For requested screens, compare screenshots against the desired reference at relevant sizes. A build, a short guide or a completed budget is not proof of good design. New directions from goals/photos still require visual judgment; this implementation has not established superiority to another design product.

A build error, such as an invalid token or component utility, is reported in the storybook. The last working HTML and CSS remain available.

Tools and commands

/proto commands: init, open, close, status, approve <id>, reject <id>, gate on|off, role <name>, on, off.

Build

npm install
npm --prefix viewer install
npm run check && npm test
npm run test:browser    # uses installed Playwright Chromium
npm run build:pi        # viewer + extension, into ~/.pi/agent/builds/pi-proto

The daemon also exposes the same operations over MCP at /mcp, with the storybook as an MCP App.

Restart Pi to load the compiled extension.
