bpx-endpoints — every model endpoint, one command | pi extension

pi ships with presets for the big hosted providers, and that's fine until your models live somewhere pi has never heard of. A load balancer in front of your model accounts. The vLLM box under the desk. A regional gateway with its own key dance. The stock answer is hand-editing ~/.pi/agent/models.json, then hand-updating it every time the endpoint's model list changes — which is exactly the kind of chore I build tools to kill.

bpx-endpoints puts all of it behind one command: /endpoints. Point an endpoint at pi and it discovers the model list, pulls parameter metadata from pi's registry plus models.dev, generates the config, and registers the endpoint into your live session. One pi-native panel holds the model-by-model knobs; refresh and doctor keep it honest over time.

Works in pi (the coding agent, v0.80+).

What it's for

pi's built-in presets already cover the known providers with correct base URLs and metadata, so this extension doesn't duplicate a preset catalog. It covers everything the presets don't:

• OpenAI-compatible proxies and load balancers
• Self-hosted endpoints (LM Studio, Ollama, vLLM)
• Regional gateways
• Any deployment where you supply the base URL, protocol, and key yourself

Install

pi install npm:@booplex/bpx-endpoints

Quick start

1. Run /endpoints and press a to add an endpoint.
2. Fill in the form: an id, the base URL (http://localhost:11434/v1 for a local Ollama, say), the API protocol, and the key — or Authentication None for open local endpoints.
3. Choose how models are discovered: the endpoint's own /models list (default) or manual ids. Press ctrl+t to test the connection, ctrl+s to save.

That's it. The models register into your running pi session immediately — no restart, no hand-written JSON. From the manager you can refresh (r), edit, clone (y), delete (x), and drill into per-model settings.

Commands

/endpoints                 Open the Endpoint Manager
/endpoints add             Add an endpoint through interactive prompts
/endpoints settings        Edit extension settings (same picker as /consult)
/endpoints status          Print a config / cache / generated read-out
/endpoints list            List endpoints
/endpoints refresh         Refresh all enabled endpoints
/endpoints refresh <id>    Refresh a single endpoint
/endpoints test <id> [model]   Send a test message (streams, reports latency)
/endpoints test --all          Batch-test all enabled endpoints (one confirm)
/endpoints probe-reasoning [id]  Probe accepted reasoning_effort values
/endpoints doctor          Diagnose config / cache / generated / custom state
/endpoints export [path]   Write masked effective generated + custom config
/endpoints open            Show the config file + state directory paths

The manager is the primary interface; the subcommands are shortcuts for scripting and recovery. It renders as a framed, solid panel centered at 104 columns — filled with your theme's card background, selected rows highlighted — so it reads as a dialog instead of more chat text. Model management, refresh, and completion happen inside the same panel session; the advanced override layer is one keystroke away.

Discovery, metadata, and refresh

Discovery runs in two modes: the endpoint's own model list (discovery.mode: "endpoint" + modelsPath) or manual entry (discovery.mode: "manual" + modelIds). A few things worth knowing about how discovery behaves:

• Full URL override: discovery.modelsUrl bypasses baseUrl + path entirely — for endpoints like Ollama whose chat API lives at .../v1 but model list at http://host:11434/api/tags.
• Path probing (discovery.probe: true): when the configured URL 404s or returns something unexpected, bpx-endpoints tries the common variants (/models, /v1/models, /api/tags, /api/models) at the origin. Never on auth failures — 401/403 are reported, not guessed around. The resolved URL is cached per profile.
• Response shapes: bare arrays, data[], models[], data.models[] nesting, and object-keyed maps all parse. Duplicate ids drop, id-less entries skip — both counted in warnings you'll see in doctor.
• Retries: transient network errors, 429 (honoring Retry-After), and 5xx retry with backoff. Auth failures don't.
• Parameter sources come from pi's built-in metadata plus a models.dev sync cached locally (24h TTL, offline fallback), so refresh works when you're offline. Fuzzy matches surface as warnings; you can pick a different source per model from the manager.
• Inclusion policy is include-all with exclusions by default, or includeOnly with an explicit list.

Reasoning efforts

OpenAI-compatible endpoints reject unknown reasoning_effort values, and pi's thinking levels (low through xhigh) don't map onto every server's schema. So bpx-endpoints never copies a metadata source's thinkingLevelMap verbatim; it always emits a complete map:

• Unknown endpoint → a canonical low/medium/high map that no pi level can leak through.
• Live probe (discovery.reasoningProbe: true, or ctrl+r in the models view) → tiny 1-token requests per candidate value (low/medium/high/xhigh/minimal/none, max 3 models per refresh) record which values the endpoint actually accepts, and the map picks the nearest accepted value for every pi level. Evidence caches per model — one model's result is never reused for its siblings.
• Error mining → when a probe or test message 400s with an effort-specific rejection that declares its supported set ("Supported types are xhigh (default), medium, and low"), the declared values are mined and unioned into the map. A failed test message that teaches the profile something updates the map immediately.
• Manual override (reasoningEfforts: ["low", "medium"]) → wins over probe results.
• An endpoint that accepts no effort value registers its reasoning models as non-reasoning, with a doctor note pointing at the pi-native alternative (compat.supportsReasoningEffort: false + a thinkingFormat).

When the endpoint accepts none, pi's off level maps to it — a real zero-thinking setting, not "think a little".

Precedence, explicit: your authored thinkingLevelMap (models.custom.json override) always wins. Complete maps pass through untouched; partial maps keep their authored entries — null values included, which pi hides from the level picker — and only missing keys are filled from the best evidence available. Then manual reasoningEfforts, then per-model probe evidence, then canonical.

Keys, headers, and baseUrl references

Endpoints authenticate with apiKey (sent as Authorization: Bearer ...) unless you choose None and provide auth through custom headers. Secrets don't have to be literals in the config:

• $VAR and ${VAR} expand from the environment; !command runs a shell command and uses its stdout. Header values and apiKey accept both; baseUrl accepts them too, including mid-URL: "baseUrl": "http://${MY_HOST}:8080/v1".
• Expansion happens at use time — discovery, tests, and registration — so config files keep the reference and nothing resolved lands on disk. An unset variable fails fast with the profile id in the message. !command must be the whole value.
• A profile setting both apiKey and a custom Authorization header gets a doctor warning: pi appends the bearer token last, so it would silently win.

Configuration

Managed config lives in a single flat file at ~/.pi/agent/bpx-endpoints.json (the pi-native path, beside pi's own state) — TypeBox-schema validated, fail-soft on load, crash-resistant on save. Derived state lives under ~/.pi/agent/bpx-endpoints/:

File	Purpose
bpx-endpoints.json	Managed user intent: endpoint profiles + settings
cache.json	Discovered models, metadata candidates, per-profile test health
models.generated.json	Generated pi models.json-shaped config
models.custom.json	Unrestricted override layer, merged after the generated config
models.dev.json	Local models.dev catalog cache

The config directory is created 0700; extension-owned JSON files are written 0600. The extension never writes to pi's native ~/.pi/agent/models.json — that file stays yours.

On first run, existing state migrates automatically (from bpx-endpoints/config.json or the legacy ~/.pi/agent/custom-provider/ directory), so existing endpoints survive the switch. Startup never touches the network; it merges and registers locally. Caches older than the stale threshold (default 7 days, settings.staleReminderDays) trigger a gentle reminder and a doctor warning.

Error handling

Situation	Behavior
Missing models.generated.json	Normal onboarding; no endpoints registered
Invalid models.generated.json	Registration skipped, but /endpoints, refresh, doctor, and recovery still work
Invalid models.custom.json	Ignored with a warning; generated endpoints still register
Invalid bpx-endpoints.json	Already-generated endpoints still register, but edit/refresh enter recovery until fixed; /endpoints settings refuses to open over a broken file rather than overwrite it
Unresolved API protocol	The affected endpoint is invalid — not generated, not registered, no silent fallback

Development

git clone https://github.com/gabelul/bpx-mono
cd bpx-mono
npm install
npm run check   # typecheck + tests, monorepo-wide

Issues and PRs at gabelul/bpx-mono.
